When a standard wheel does not fit your machine or part, we make it to your drawing. Fengzuan produces custom diamond grinding wheels and CBN wheels in special shapes and profiles, in resin, vitrified and bronze bonds. Send a drawing, a sample or the marking on your current wheel and we will confirm feasibility, recommend a specification and quote.
Custom Wheel Specifications
| Parameter | Range / option |
|---|---|
| Abrasive | Diamond or CBN |
| Bond | Resin (B), vitrified (V) or bronze |
| Outer diameter (D) | Ø10–850 mm |
| Thickness (T) / bore (H) | Made to your drawing / to suit your machine spindle |
| Abrasive layer (X) | 3–20 mm common; other depths to drawing |
| Grit | 80# – 3000# |
| Concentration | 50 – 150 |
| Shapes | 1A1, 6A2, 6A2T, 11A2, 12A2, 14E1, 14A1, 1A8/1A1W, 1A1R and profiles to drawing |
| Coolant | Wet or dry (confirm per specification) |
| Marking example | 1A1 D150 T10 X5 H32 · D/CBN 140/170 C75 B/V/R |
Shape Codes We Produce
1A1 straight wheel
Flat straight wheel with the abrasive on the periphery; the most common shape for cylindrical, surface and flute grinding.
6A2 cup wheel
Straight cup wheel with the abrasive on the face, for face and surface grinding.
6A2T cup wheel
A cup wheel variant for surface and face grinding, made to your drawing.
11A2 flaring cup wheel
Tapered cup for sharpening clearance faces of end mills, drills and cutters.
12A2 dish wheel
Thin dish for rake faces, gashes and saw tips in tool and cutter grinding.
14E1 V-edge wheel
V-shaped edge for grooves, flutes, threads and profiles; angle and tip radius to drawing.
14A1, 1A8/1A1W and 1A1R
14A1 wheels for profiles, 1A8/1A1W internal grinding wheels, and 1A1R thin wheels for cut-off and slotting.
Applicable Workpiece Materials
- Tungsten carbide, ceramics, glass and glass-ceramics (diamond)
- PCD / PDC compact (diamond)
- HSS, tool steel, die steel and bearing steel (CBN)
- Tools, molds, cutters and drills
How It Works
- Send your drawing or sample with dimensions, tolerances and workpiece material.
- We review feasibility and suggest bond, grit and concentration.
- We send a quotation and confirm the final drawing with you.
- The wheel is made and checked against the approved drawing.
- Export packing and express shipment.
Bond Advantages for Custom Shapes
- Resin: sharp cutting, self-dressing, fine finish
- Vitrified: controlled porosity and profile holding
- Bronze: high holding power, long life, excellent heat conduction
Ordering, Samples and Delivery
- MOQ: 15 pcs per specification
- Samples: produced within 30 days; sample cost and freight are charged
- Bulk production: within 45 days after drawing confirmation
- Payment: PayPal · Trade term: FOB · Shipping: international express
- Export markets served: Russia, USA, Germany, UAE and Qatar
What to send for a fast quote
- Shape code and full size (D, T, X, H, layer width, angles or radii)
- Diamond or CBN, grit and concentration (if known)
- Bond preference: resin (B), vitrified (V) or bronze/metal
- Workpiece material and machine model, wet or dry grinding
- Quantity, required lead time and destination
Frequently Asked Questions
Can you make a wheel from only a sample?
Yes. Send the sample or clear photos with measurements and its marking; we will draft a drawing for your confirmation.
What file formats do you accept?
PDF, DWG, DXF, JPG and PNG drawings can be sent through the contact form or by email.
What size range can you produce?
Diameters from Ø10 to 850 mm, grit 80#–3000#, concentration 50–150. Thickness and bore are made to your drawing.
Is there an MOQ for custom shapes?
MOQ is 15 pcs per specification. Samples are available within 30 days; sample and freight are charged.
How long does production take?
Bulk orders are produced within 45 days after the drawing is confirmed.
Send Your Drawing
Upload your drawing or describe the wheel you need. We will confirm feasibility and send a quotation. Email lw892398@gmail.com or WhatsApp +86 13282830167. We reply within 24 hours (China Standard Time, UTC+8).
